ANGIS DEFENSE is the only patented electronic tripwire system redefining the approach to perimeter protection and tactical security solutions in the defense industry.
TDS1
Watch product video ↓Deep in the forests of Northern Europe lives the only venomous snake — the ANGIS. It is not the largest or the fastest predator. Yet it has a quality respected even by the strongest animals — a precise, sudden, and decisive strike. The viper does not move without reason. It waits. It observes. And when the moment comes, it strikes with precision. This philosophy became the foundation of ANGIS DEFENSE.
TDS-1 is designed for rapid deployment, effective force protection, and flexible use across various operational environments. The system is simple to operate, reliable in performance, and suitable for both training exercises and real-world defensive scenarios.
The ANGIS DEFENSE system is currently being tested in an SOF environment, with initial trial results proving positive. Practical feedback confirms the product’s relevance, functionality, and potential to become a significant solution in the field of modern perimeter protection and tactical signaling systems.
The goal of ANGIS DEFENSE is to become a new standard in perimeter protection and tactical signaling systems.
Details
TDS-1 incorporates an integrated line reel, an audible alarm, and operates in either acoustic or explosive detonation modes.
USE CASES:
- Training — safe use with an audible alarm.
- Perimeter security — helps detect breaches in advance.
- Neutralization of armored and personnel targets – Compatible with all types of explosives using electric detonators. A key advantage of TDS-1 is that explosive charges can be placed at a distance from the tripwire unit using wired connections, enabling flexible positioning.
THREE TRIGGER SCENARIOS:
Tension/Tripping: Pulling a taut tripwire moves the clip to the maximum position.
Cutting: Cutting a taut tripwire allows the clip to snap back to its resting state, activating the unit.
Slack/Hooking: For loose wires with hooks, a safety insert prevents activation until the wire is snagged. Once pulled, the insert falls out, and the clip either snaps back or pulls forward to trigger the device.
SAFETY FEATURES:
Safe activation with a 2 min delay (according to customer requirements)
Safe deactivation using an additional accessory
Automatic deactivation after 2 weeks (according to customer requirements)
Key:
1 – Tripwire spool;
2 – Spool retaining/tightening nut;
3 – Deactivation point;
4 – Activation Red LED;
5 – Green LED;
6 – Activation and arm button;
7 – Battery cover;
8 – Electric detonator wire terminal clips;
9 – Integrated alarm;
10 – Electric detonator wire terminals;
11 – Holes for mounting the device to various surfaces;
12 – Tripwire recess/groove;
13 – Hole for threading the tripwire into the clip;
14 – Clip (pressing it upwards opens hole 13);
15 – Deactivation blue LED.
WEIGHT: 140 g
DIMENSIONS: 105 × 50 × 25 mm
BATTERY: Li-ion 18650
OPERATING TIME: 30 days (with a fully charged 3500 mAh battery)
OPERATING TEMPERATURE: from -40 °C to +70 °C
INITIATION PARAMETERS:
– Up to 3 J pulse
– Up to 32 V voltage
– Up to 60 A current
– Maximum test current 14 µ
360°
INFORMATION
TDS-1 incorporates an integrated line reel, an audible alarm, and operates in either acoustic or explosive detonation modes.
USE CASES:
- Training — safe use with an audible alarm.
- Perimeter security — helps detect breaches in advance.
- Neutralization of armored and personnel targets – Compatible with all types of explosives using electric detonators. A key advantage of TDS-1 is that explosive charges can be placed at a distance from the tripwire unit using wired connections, enabling flexible positioning.
THREE TRIGGER SCENARIOS:
- Tension/Tripping: Pulling a taut tripwire moves the clip to the maximum position.
- Cutting: Cutting a taut tripwire allows the clip to snap back to its resting state, activating the unit.
- Slack/Hooking: For loose wires with hooks, a safety insert prevents activation until the wire is snagged. Once pulled, the insert falls out, and the clip either snaps back or pulls forward to trigger the device.
SAFETY FEATURES:
- Safe activation with a 2 min delay (according to customer requirements)
- Safe deactivation using an additional accessory
- Automatic deactivation after 2 weeks (according to customer requirements)
Key:
1 – Tripwire spool;
2 – Spool retaining/tightening nut;
3 – Deactivation point;
4 – Activation Red LED;
5 – Green LED;
6 – Activation and arm button;
7 – Battery cover;
8 – Electric detonator wire terminal clips;
9 – Integrated alarm;
10 – Electric detonator wire terminals;
11 – Holes for mounting the device to various surfaces;
12 – Tripwire recess/groove;
13 – Hole for threading the tripwire into the clip;
14 – Clip (pressing it upwards opens hole 13);
15 – Deactivation blue LED.
GALLERY
SPECIFICATIONS
WEIGHT: 140 g
DIMENSIONS: 105 × 50 × 25 mm
BATTERY: Li-ion 18650
OPERATING TIME: 30 days (with a fully charged 3500 mAh battery)
OPERATING TEMPERATURE: from -40 °C to +70 °C
INITIATION PARAMETERS:
– Up to 3 J pulse
– Up to 32 V voltage
– Up to 60 A current
– Maximum test current 14 µ
